Designed for efficiency, this CNC machine accelerates production with high-speed features that minimize cycle times and maximize throughput. A dual-supported tilting table and fast rapid traverse rates enable precise, dynamic motion, while the standard 30-tool changer—expandable to 60, 90, or 120 tools—ensures fast tool access and reduced setup time. Whether handling complex part geometries or high-volume workflows, this machining center delivers reliable, repeatable results in demanding shop environments.
Variaxis C-700 Features:
| Model | Variaxis C-600 |
|---|---|
| Pallet size | 23.62 × 19.69 |
| Tool shank | 40 |
| Max. spindle speed | 12000 |
| Max. workpiece size | 28.74 × 17.72 |
$1.00
The Mazak Variaxis C-700 is a next-generation high-speed CNC machining center built to meet the demands of modern subtractive manufacturing. Engineered for precision, efficiency, and adaptability, this machine delivers exceptional performance in a compact format. Its rigid structure and thermal stability ensure consistent accuracy during extended machining operations, while its work envelope supports a wide range of part sizes and geometries. The C-700 delivers advanced subtractive machining for complex components and serves aerospace, medical, and industrial applications.
With full simultaneous 5-axis capability, the Variaxis C-700 allows manufacturers to complete intricate parts in a single setup. As a result, they can eliminate multiple fixturing steps and reduce cycle times. Designed for high-mix production environments, it provides exceptional part accuracy and repeatability. Efficient chip evacuation and thermal management further enhance its performance, making it a trusted solution for shops focused on throughput, consistency, and tight-tolerance results.
The Mazak machining center is equipped with an advanced SmoothAi CNC control for improved precision and intelligent process management. Features such as SMOOTH Machining Configuration (SMC) and Ai Thermal Shield automatically adjust cutting parameters and compensate for thermal displacement in real time—ensuring stable, high-accuracy performance during long production runs.
The C-700 integrates with Pallatech to become a pallet changer CNC machine for continuous operation through automated part loading and unloading. This automation capability also supports lights-out production, minimizes operator involvement, and increases overall machine utilization. As a result, the Variaxis C-700 is a strong solution for high-efficiency subtractive machining environments.
| Model | Variaxis C-600 |
|---|---|
| Pallet size | 23.62 × 19.69 |
| Tool shank | 40 |
| Max. spindle speed | 12000 |
| Max. workpiece size | 28.74 × 17.72 |
| Table | Table size | Φ700 mm × 500 mm |
|---|---|---|
| Max. workpiece size | Φ850 mm × 500 mm | |
| Max. load (evenly distributed) | 700 kg | |
| Spindle | Tool shank | BT40 |
| Max. spindle speed | 12000 min-1 | |
| Max. torque (40% ED) | 70 Nï½¥m | |
| Max. torque (cont. rating) | 57.3 Nï½¥m | |
| Spindle motor (40% ED) | 11 kW (15 HP) | |
| Spindle motor (cont. rating) | 11 kW (15 HP) | |
| Automatic tool changer | Tool storage capacity | 30 |
| Max. tool diameter | Φ80 mm | |
| Max. tool diameter (without adjacent tool) | Φ130 mm | |
| Max. tool length (from gauge line) | 300 mm | |
| Max. tool weight | 8 kg | |
| Travel | X-axis | 860 mm |
| Y-axis | 600 mm | |
| Z-axis | 530 mm | |
| B-axis | -30° – +120° | |
| Distance from table top to spindle nose (table horizontal) | 100 mm to 630 mm | |
| Rapid traverse rate | X-axis | 42000 mm/min |
| Y-axis | 42000 mm/min | |
| Z-axis | 42000 mm/min | |
| Machine size | Machine width × length (MAZATROL SmoothAi) | 2600 mm × 3135 mm |
| Height | 3189 mm | |
| Machine weight | 11200 kg |
