Mazak Syncrex 38 Swiss-style CNC lathe for Swiss turning, small-part production lathe applications, and high-volume production turning machine efficiency.

Syncrex 38

The Mazak Syncrex 38 is a precision-engineered Swiss-style CNC lathe built for high-volume manufacturing. Designed as a robust small-part production lathe, it combines the accuracy of Swiss turning with the throughput of a modern production turning machine. With HDCC stability, automation readiness, and multi-tool flexibility, it delivers consistent performance for demanding industries.



Mazak Syncrex Features and Benefits

  • 20 mm and 25 mm models include standard 10,000 rpm main and sub spindles
  • Machines run full bar capacity with no special bar end prep
  • Spline-connected sliding head spindle for greater accuracy and less material waste
  • Removable guide bushing adapter enables operators to preset guide bushing outside the machine
  • Exclusive Mazak Auto Tool Setter in the machine reduces setup time
  • Mazak HDCC machine base for increased machine stability and rigidity
Model

Syncrex 38/7, Syncrex 38/8, Syncrex 38/9
Max Machining Diameter

1.5
Max. spindle speed

8000
Number of tools

27, 36, 39

$1.00

SKU N/A Categories: , Brand:
Description
Swiss-Style CNC Lathe for Precision Production

The Mazak Syncrex 38 is a high-performance Swiss-style CNC lathe built for efficiency, accuracy, and scalability. As a small-part production lathe, it supports industries that depend on Swiss turning to achieve tight tolerances on complex geometries. With advanced features designed for production turning machine applications, it improves throughput while maintaining consistent quality in high-volume operations.



Engineered for Stability with HDCC Technology

The Syncrex 38 uses High Damping Composite Casting (HDCC) for maximum rigidity and vibration control. This design ensures thermal stability, longer tool life, and superior surface finishes, even under demanding production conditions. Compared to conventional builds, it provides greater durability and machining consistency, which is an asset for extended high-volume runs.



Swiss Turning with Automated Efficiency

To maximize spindle utilization, the Syncrex 38 integrates with bar feeder systems for continuous, unattended production. Multi-tool configurations expand cutting flexibility, reduce setup time, and support faster changeovers. As a production turning machine, it combines an automation-ready design with precise Swiss turning to give manufacturers the speed and reliability needed for competitive, large-scale production.

Additional Information
Model

Syncrex 38/7, Syncrex 38/8, Syncrex 38/9
Max Machining Diameter

1.5
Max. spindle speed

8000
Number of tools

27, 36, 39
Syncrex 38/7
Capacity Max. machining diameter Φ1.5″
Max. machining length GB (one chucking) 12.59″
Main Spindle Max. spindle speed 8000 rpm
Power requirement (40% ED) 7.5 kW (10 HP)
Second Spindle Max. spindle speed 8000 rpm
Power requirement (40% ED) 7.5 kW (10 HP)
Turret Number of tools 27
OD 11
Cross live tool 4
Back working 4
Boring bar holder (Main / Sub) 4 / 4
Rapid traverse rate X1-axis 1378 IPM
Y1-axis 1378 IPM
Z1-axis 1378 IPM
X2-axis 1378 IPM
Y2-axis 1378 IPM
Z2-axis 1378 IPM
Machine size Width × Depth (MAZATROL SmoothSt) 52″ × 99.2″
Height 78.9″
Weight 1200 lbs

*B-axis Contouring : 9X Model only

Syncrex 38/8
Capacity Max. machining diameter Φ1.5″
Max. machining length GB (one chucking) 12.59″
Main Spindle Max. spindle speed 8000 rpm
Power requirement (40% ED) 7.5 kW (10 HP)
Second Spindle Max. spindle speed 8000 rpm
Power requirement (40% ED) 7.5 kW (10 HP)
Turret Number of tools 36
OD 11
Cross live tool 4
Back working 8
End working tools 5
Boring bar holder (Main / Sub) 4 / 4
Rapid traverse rate X1-axis 1378 IPM
Y1-axis 1378 IPM
Z1-axis 1378 IPM
X2-axis 1378 IPM
Y2-axis 1378 IPM
Z2-axis 1378 IPM
Machine size Width × Depth (MAZATROL SmoothSt) 52″ × 99.2″
Height 78.9″
Weight 1200 lbs

*B-axis Contouring : 9X Model only

Syncrex 38/9
Capacity Max. machining diameter Φ1.5″
Max. machining length GB (one chucking) 12.59″
Main Spindle Max. spindle speed 8000 rpm
Power requirement (40% ED) 7.5 kW (10 HP)
Second Spindle Max. spindle speed 8000 rpm
Power requirement (40% ED) 7.5 kW (10 HP)
Turret Number of tools 39
OD 8
Cross live tool 4
Back working 8
End working tools 5
Boring bar holder (Main / Sub) 4 / 4
B-axis Tool* (Main / Sub) 3 / 3
Rapid traverse rate X1-axis 1378 IPM
Y1-axis 1378 IPM
Z1-axis 1378 IPM
X2-axis 1378 IPM
Y2-axis 1378 IPM
Z2-axis 1378 IPM
Machine size Width × Depth (MAZATROL SmoothSt) 52″ × 99.2″
Height 78.9″
Weight 1200 lbs

*B-axis Contouring : 9X Model only
