Syncrex 20/9X

Precision Performance: 5-Axis Swiss-Style Machining for Micro Parts

The Mazak Syncrex 20/9X is a high-performance Swiss lathe engineered for precision and efficiency in small-component production. It delivers full 5-axis Swiss-style machining through its B-axis tool post. As a result, machinists can achieve intricate contours and complex geometries in a single setup. The 20/9X is ideal for high-mix prototyping and light- to medium-volume production runs because of the compact 20 mm bar capacity and max capability of 36 tools (20 static and 16 live).

Stability and Accuracy: HDCC Base & Advanced Spindle Design

Constructed on a rigid one-piece HDCC foundation, the Syncrex 20/9X achieves 10% greater rigidity compared to traditional cast-iron designs. In addition, the advanced base reduces vibration by up to 80% and minimizes thermal growth, extending tool life by 30%. It also featured spline-connected sliding, which enhances precision while reducing material waste. As a result, these innovations deliver consistent accuracy, long-term stability, and superior surface finishes during long production runs.

Streamlined Setup and Control: Productivity Built In

Mazak Swiss machines include removable guide bushing adapters. As a result, operators can decrease downtime by performing setup tasks offline.In addition, the MAZATROL SmoothSt CNC control features an intuitive 15-inch touchscreen and full keyboard for faster programming and simplified operation. Machine shops can also increase usability and throughput with consistent precision by taking advantage of optional packages like Mazak Swiss Setup Assist and Dynamic Chip Control.
