Mazak Syncrex 20 Swiss-style CNC lathe for precision Swiss turning with Smooth CNC control and bar feeder CNC machine integration.

Syncrex 20

The Mazak Syncrex 20 is a compact yet powerful Swiss-style CNC lathe designed for precision, speed, and stability in small-diameter part production. Ideal for Swiss turning in a variety of industries, it delivers tight-tolerance with reliable accuracy. With Smooth CNC Control, modular tooling flexibility, and seamless bar feeder integration, the Syncrex 20 is engineered to maximize efficiency and consistency in high-volume or high-mix environments.



Mazak Syncrex 20 Features:

  • >20 mm and 25 mm models include standard 10,000 rpm main and sub spindles
  • Machines run full bar capacity with no special bar end prep
  • Spline-connected sliding head spindle for greater accuracy and less material waste
  • <span style=”font-weight: 400;”>Removable guide bushing adapter enables operators to preset guide bushing outside the machine</spa
  • Exclusive Mazak Auto Tool Setter in the machine reduces setup time
  • Mazak HDCC machine base for increased machine stability and rigidity
Model

Syncrex 20/7, Syncrex 20/8, Syncrex 20/9
Max Machining Diameter

0.75
Max. spindle speed

10000
Number of tools

29, 33, 36

$1.00

SKU N/A Categories: , Brand:
Description
Swiss-Style CNC Lathe for Precision Performance

The Mazak Syncrex 20 is a premier Swiss-style CNC lathe built for speed, stability, and accuracy in small-diameter part production. Ideal for Swiss turning in a variety of industries, it provides tight-tolerance results with the reliability needed for continuous, unattended machining. Equipped with Smooth CNC Control, the Syncrex 20 simplifies complex machining tasks with an intuitive interface and built-in optimization features. For example, operators can manage intricate geometries, reduce setup time, and optimize cutting strategies to enhance productivity across multiple shifts.



Tooling CNC Lathe with Bar Feeder Integration

As a versatile tooling CNC lathe, the Syncrex 20 integrates seamlessly with a bar feeder CNC machine for extended, uninterrupted production. As a result, job shops will see consistent raw material loading, minimized downtime, and great support on high-volume runs. In addition, the modular tooling stations feature quick-change capabilities for fast part transitions and increased flexibility in high-mix manufacturing. The tooling system is also durable and withstands multi-shift operations with maintained precision and repeatability.



Compact Swiss Turning Solution with Scalable Performance

The Syncrex 20 is a high performance, detailed Swiss machine in a compact footprint. Its rigid base and advanced thermal stability ensure consistent dimensional accuracy during long production cycles. Supporting reliable Swiss turning, it delivers precision for both small-batch and large-volume manufacturing. The Syncrex 20 Swiss-style CNC lathe is engineered for scalability with bar feeder integration to deliver throughput, consistency, and efficiency for modern job shop production demands.


Additional Information
Model

Syncrex 20/7, Syncrex 20/8, Syncrex 20/9
Max Machining Diameter

0.75
Max. spindle speed

10000
Number of tools

29, 33, 36
Syncrex 20/7
Capacity Max. machining diameter Φ0.75″
Max. machining length GB (one chucking) 8.07″
Main Spindle Max. spindle speed 10000 rpm
Power requirement (40% ED) 3.7 kW (5 HP)
Second Spindle Max. spindle speed 10000 rpm
Power requirement (40% ED) 3.7 kW (5 HP)
Turret Number of tools 36
OD
Cross live tool 4
Back working 8
End working tools 2
Boring bar holder (Main / Sub) 4 / 4
Rapid traverse rate X1-axis 1377 IPM
Y1-axis 1377 IPM
Z1-axis 1377 IPM
X2-axis 1377 IPM
Y2-axis 1377 IPM
Z2-axis 1377 IPM
Machine size Width × Depth (MAZATROL SmoothSt) 48.23″ × 88.58″
Height 66.93″
Weight 7850 lbs

*B-axis Contouring : 9X Model only

Syncrex 20/8

<!– Y1-axis 1377 IPM Z1-axis 1377 IPM X2-axis 1377 IPM Y2-axis 1377 IPM 1377 IPM Machine size Width × Depth (MAZATROL SmoothSt) 48.23″ × 88.58″ Height 66.93″ Weight 7850 lbs *B-axis Contouring : 9X Model only

Syncrex 20/9
Capacity Max. machining diameter Φ0.75″
Max. machining length GB (one chucking) 8.07″
Main Spindle Max. spindle speed 10000 rpm
Power requirement (40% ED) 3.7 kW (5 HP)
Second Spindle Max. spindle speed 10000 rpm
Power requirement (40% ED) 3.7 kW (5 HP)
Turret Number of tools 36
OD 8
Cross live tool 4
Back working 8
End working tools 2
Boring bar holder (Main / Sub) 4 / 4
B-axis Tool* (Main / Sub) 3 / 3
Rapid traverse rate X1-axis 1377 IPM
Y1-axis 1377 IPM
Z1-axis 1377 IPM
X2-axis 1377 IPM
Y2-axis 1377 IPM
Z2-axis 1377 IPM
Machine size Width × Depth (MAZATROL SmoothSt) 48.23″ × 88.58″
Height 66.93″
Weight 7850 lbs
*B-axis Contouring : 9X Model only –>

Capacity Max. machining diameter Φ0.75″
Max. machining length GB (one chucking) 8.07″
Main Spindle Max. spindle speed 10000 rpm
Power requirement (40% ED) 3.7 kW (5 HP)
Second Spindle Max. spindle speed 10000 rpm
Power requirement (40% ED) 3.7 kW (5 HP)
Turret Number of tools</th> 33
OD 11
Cross live tool 4
Back working 8
End working tools 2
Boring bar holder (Main / Sub) 4 / 4
Rapid traverse rate X1-axis 1377 IPM
