The Mazak HQR 100 is a compact multi-tasking CNC machine designed for high-volume, small-part production. With dual spindles, twin turrets, and Smooth CNC control, it delivers fast setups, reduced cycle times, and reliable high-precision CNC turning. Its compatibility with bar feeder CNC machine integration makes it ideal for continuous production in industries such as aerospace, medical, and electronics.
HQR 100 Features:
| Model | HQR 100MSY |
|---|---|
| Chuck Size | |
| Max Machining Diameter | 11.625 |
| Max Machining Length | 24.375 |
$1.00
The Mazak HQR 100 is a compact, high-performance multi-tasking CNC machine designed for fast, precise machining of small components. Built for industries requiring high-volume accuracy, it integrates dual spindles and twin turrets to deliver maximum productivity in a space-saving footprint.
Equipped with advanced Smooth CNC control, the HQR 100 streamlines programming, tool path optimization, and real-time monitoring. Its conversational interface reduces setup time and operator training, keeping uptime high. With twin turrets supporting simultaneous upper and lower cutting, the machine achieves consistent high-precision CNC turning with rapid throughput. As a result, it’s ideal for aerospace, medical, and electronics applications.
The HQR 100 integrates seamlessly with bar feeders, operating as a reliable bar feeder CNC machine for continuous production. This setup ensures steady material feed, reduced downtime, and greater efficiency in both high-volume runs and small-batch jobs. As a small-part production lathe, it maintains repeatability and superior surface finishes, helping manufacturers balance precision and speed in flexible production environments.
| Model | HQR 100MSY |
|---|---|
| Chuck Size | |
| Max Machining Diameter | 11.625 |
| Max Machining Length | 24.375 |
| Universal | Universal type | 600U |
|---|---|---|
| Spindle | Chuck size | 6 “ |
| Max. spindle speed | 6000 rpm | |
| Max. torque (25%ED) | 119.5 ft-lbs | |
| Spindle motor (30 min. rating) | 11 kW (15 HP) | |
| Spindle motor (cont. rating) | 7.5 kW (10 HP) | |
| Second spindle | Chuck size | 6 “ |
| Max. spindle speed | 6000 rpm | |
| Spindle motor (30 min. rating) | 11 kW (15 HP) | |
| Spindle motor (cont. rating) | 7.5 kW (10 HP) | |
| Upper and lower turret | Tool storage capacity | 12 |
| Tool shank height | 1 “ | |
| Boring bar shank diameter | Φ1 “ | |
| Rotary tool spindle | Max. spindle speed | 6000 rpm |
| Max. torque (3 min. rating) | 26 ft-lbs | |
| Spindle motor (10 min. rating) | 5.5 kW (7.5 HP) | |
| Spindle motor (cont. rating) | 2.2 kW (3 HP) | |
| Travel | X-axis (upper turret / lower turret) | 7 ” / 4 “ |
| Y-axis (upper turret / lower turret) | 4″ (±2″) / 4″ (±2″) | |
| Z-axis (upper turret / lower turret) | 20 ” / 23 “ | |
| Rapid traverse rate | X-axis (upper turret / lower turret) | 1181 IPM / 945 IPM |
| Y-axis (upper turret / lower turret) | 1024 IPM / 787 IPM | |
| Z-axis (upper turret / lower turret) | 1575 IPM / 1575 IPM | |
| Machine size | Width × Length (MAZATROL SmoothG) | 113 ” × 91 “ |
| Height | 96 “ | |
| Machine weight | 20194 lbs |
