The Mazak FG-220 is a high-performance 3D tube laser cutting machine designed for structural and fabrication work. It processes round, square, rectangular, and irregular profiles in a single setup. As a pipe laser cutter powered by solid-state technology, it delivers clean edges, minimal distortion, and consistent accuracy across every cut. Built for long-length processing and full automation, it provides an efficient solution for manufacturers seeking speed, flexibility, and precision in tube and pipe production.
Fg-220 Features:
The Mazak FG-220 is a high-performance 3D tube laser cutting machine engineered for speed, accuracy, and flexibility. For example, it processes round, square, rectangular, and irregular tubing in a single setup. As a solid-state pipe laser cutter, it also ensures clean edges and minimal heat distortion while maintaining tight tolerances. This makes it a reliable solution for manufacturers handling structural components, assemblies, and high-mix production runs.
Equipped with a multi-axis 3D fiber laser, the FG-220 can precisely cut angles, contours, and weld-prep features with precision. In addition, the system automatically adapts to material thickness and geometry for better consistency across mild steel, stainless, and aluminum. It also features solid-state laser pipe cutting technology to reduce rework, improve repeatability, and lower overall material waste. This capability positions the FG-220 as a versatile pipe laser cutter that supports complex workflows in demanding industries.
Designed for automation, the FG-220 integrates loading, alignment, and cutting functions for faster cycle times and reduced labor input. It supports pipe stock up to 26 feet long, holding material securely for accurate results without secondary operations. By combining long-length processing with advanced automation, this 3D tube laser cutting machine helps manufacturers increase throughput while reducing downtime.
FG-220
| Specifications | Loader specifications | 118.1″ |
|---|---|---|
| Workpiece size | Workpiece shape | round, square, L beam, H beam, I beam, channel |
| Workpiece material | mild steel, stainless steel, copper, brass, aluminum | |
| Max. workpiece diameter (round pipe) | Φ0.79″ – Φ8.66″ | |
| Max. workpiece diameter (square pipe) | 0.79″ × 0.79″ – 6.0″ × 6.0″ | |
| Max. material length for unloading | 118.11″ | |
| Max. workpiece weight | 298 lbs | |
| Max. workpiece weight (per 1 ft) | 30 lbs/ft | |
| Laser resonator | Laser power | 4.0 kW |
| CNC | Control method | semi-closed loop |
| Max. controlled axes | 32 | |
| Min. program increment | 0.0001″ | |
| Programming method | EIA / ISO | |
| Monitor | 15″ color LCD | |
| Machine size | Machine width × length | 226″ × 227″ |
| Machine height | 108″ |
* option
